PRODUCT SUMMARIZE

This room is equipped with up and down double guide rail pneumatic door, gained the national utility model patent certificate.

Features: Double guide closed pneumatic door, could move up to down, left to right. Pneumatic control (SMC, FESTO brand), good effect sound-proof, product could move in and out conveniently.

Function: Assembly line mute testing, car seat, scuttle, fan and other noise testing……

Noise reduction effect: ≥25~40dB(A).

PRODUCT FEATURES

· Sound-proof room is the framework combined structure, wall thickness is 100-200mm, main structure firm and beautiful, screw holes is concealed.

· Sound-proof room equip with double guide rail closed pneumatic door, could move up and down, left to right. Pneumatic compponet is equipped with SMC or FESTO brand.

· The room is equipped with efficient closed soundproof door.

· Outer wall of sound-proof room fully use national high quality galvanized steel sheet, with 2.0mm thickness.

· Interlayer wall of sound-proof room use independent research and development complex sound absorption, pugging.

· Inner surface wall of sound-proof room choose national standard 2×2×1.0mm thickness high-quality galvanized mesh plate.

· Outer surface wall of sound-proof room use electrostatic powder coating, 220 degree high tempreature forming process, surface wear resisting and ageing resistance, scratch resistance.

· The top of room install low noise ventilation system, to balance the temperature of inner room.

· The inner room is equipped with environmental lighting lamp, inscribed safety power, electrical control switch outlet.
